YAMAHA Label feeder
Related products
D-8800A PCB Radial insertion machine
auto insertion machine: Radial insertion
A radial inserter takes radial leaded through-hole components from a reels which are fed into dispensing heads that cut the component from the reel and place it onto the chain in sequence of the order of insertion. The component is brought to a component transfer assembly behind the insertion head and is transferred to the insertion head, then inserted into the board while a clinch assembly underneath cuts and bends the leads opposite to each other.
Radial Insertion Machine • Flexible performance with lead span capabilities from single to quad-span
• Multiple clinch configurations for standard and high-density applications
Radial Component Specifications
Span: 2.5/5.0/7.5 10.0mm
Low maintenance feeder technology
Insertion Directions: 0°,90°,180°,270°
KIC X5 Furnace Temperature Tester
1.Support all the WINDOWs software platforms; USB-Key cryptographic function;
2.Brand-new dual power supply: type 7 (AAA) battery; power supply by USB (Remark: Power can be supplied after inserting into the USB port of the computer.)
3.The fifth generation of technology of KIC; launched in the market in 2012;
4.24 months ’warranty period for the hardware.
YT-1025 PCB Press fit Machine for connectors, headers, sockets,
Servo motor drive，constant pressure output control，Closed-loop control，real-time display pressure、speed、position ，using PVFS calculation.Real-time control the end pressure.It can effectively eliminate impact deformation that caused by PCB change, PCB hole tolerance, tolerance of connector pins, mold machining tolerances.Eliminating pins damage or breakage, solder bump or flux residue, etc. Avoidance of short, cold solder connection, corrosion, etc。Having log management function, pressure curve auto-save function . User management fuction, SPC management software package(option ), to traced and statistics products.Using both hands to start and platform laser protaction (Option)，effectively makesure products safety.With laser positioning and press parts position display function.Working platform with flotation structure, PCB can move and positioning easily Press head using biaxial oriented structure, to ensure the stability of the work force of the press head .
